Product Description Radio Studio 1 kW FM Turnkey Solution

FM Radio Station Package offers Professional grade, high quality FM broadcast system to start your own Radio Station at competitive price

This system contains all the equipment needed to start broadcasting

1 mixing console, for ON AIR broadcasting and for production/ recording
3 Networked PCs with Windows 7 or 8, radio production and playlist/automation software/editing/programming
2 Portable Digital Mp3 Recorders,
1 GSM Phone

A studio telephone and telephone hybrid
A top of the range 1000 Watt FM stereo transmitter and broadband FM dipole antennas, which provide sufficient power to broadcast to a range of 50km (depending on the height of the antenna/site, noise, and the terrain of the local area) 87.5 to 108 MHz in 10 kHz steps (Fully adjustable to the whole FM-band through menu), Analog and/or AES «XLR», Up to 192 kb/s @ 16, 24, 32 bits,
Tower, Cable,UPS, Diesel Generator

Package

Studio Equipment

1 8 Channel On-line cum Production Mixing Console
2 Audio Portable Digital Recorders
2 CD/MP3 Players
3 Desktop PCs with audio production and radio playlist software
3 Monitors, Keyboards, etc.
1 Telephone Hybrid
1 Dual Cassette / CD Recorder
1 FM Tuner/amplifier
1 Pair of Studio Monitor Speakers
1 Cardioid condenser Microphones
3 Dynamic Microphones
2 Pairs of Studio Headphones
1 Headphone Amplifier
2 rack
1 Tall Mic Stand
3 Table Mic Stands
Cables and Connectors
2 Recordable CDs 100 pack

Transmission Equipment

1 1KW FM Transmitter
1 Wideband Dipole Antennas, N, with clamps
1 Power Divider in 7/16 out 4 ways N with 4 1.4″ N/N conn.
1 50 Ohm 1.2″ Coaxial Cable 40 m
1 FM processor
Material for tower (guyed) 30 meters complete with aviation light, lightening arrestor, earthing material (Guyed Lattice Mast, 30 meters, Wired design, Galvanized steel, Red & white painted, Including sufficient foundation material for mast & guy wires, guy wires & mounting supplies, lightning arrester & grounding, red flash lamp on top with cable
1 Voltage Stabilizer 3 kW (single phase)
10 KVA Diesel Generator

Technical furniture

1 Announcer table
1 Discussion table
5 revolving chairs

Acoustics

Acoustic material LF 24 sq mtr
Acoustic material for mid and high frequency 48 sq mtr
False ceiling 40 sq mtr (tiles with channel)
Flooring material 40 sq mtr (PVC carpet with glue)

Extras (optional)

Equipment installation, Training and Technical Services for Community Radio and Commercial Radio to be charged extra as per site location.
